Float Switch for level monitoring

Individually adapted for your application, already available from 10 pieces



We develop and manufacture for companies
your customized float level switch,
this does not require any adjustments to your tank.

Installation from above

schwimmerschalter_vertikal_k

Installation from the side

schwimmerschalter_horizontal_k2

Stainless Steel

schwimmerschalter_edelstahl-3

Float switch – liquid level switch – level sensor

Monitor fluid level safely

Prevent your pump from running dry or overrunning your container with our float switches. This reliably monitors the liquid level in containers or water tanks. You get a signal (alarm) when it’s empty or filled. This automatically can switch your pump on or off, depending on the liquid level. So you can protect your pump from failure. Float switches are a cost-effective and maintenance-free alternative to expensive electronic sensors. Our level switches are very energy-saving as no permanent power supply is needed.

Components that fit easily

Float switches off the shelf will never exactly meet your requirements and desires.
These do not fit your application. Either you change your container or device, or you will find a manufacturer that will tailor the level switch to your needs .

We can help you here and that at standard prices. Our developers modify one of our numerous standard types or develop a completely new variant for you (OEM product).

brt-bj1

Bernd Jäger (Sales)

Do you have any questions or would you like advice?

Just call me now, call 0049 6108/7001-25
Or send me your requests

Save time and money:

  • No customization to your application is necessary by customized size

  • Easy and safe to assemble by optimal size and assembly type

  • Get connected quickly and safely through matching cables and plugs

  • The switching point is exactly at the desired level, which is by matching the components

Float switch are available as standard products or customized variants.
However, for a standard product, the switching point, size or material composition is not aligned with your application. In order for your pump to turn on or off at the desired level, you need a sensor or switch that fulfills this requirements. A suitable material should be chosen for the level switch that is suitable for the medium used, such as water or oil. On choosing the wrong material, the float switch will not work after some time.
In most cases, you will only get the best results if you only adapt your requirements and your device.

Customize the float switch exactly to your requirements.
Depending on the used liquid, the case material and the float must be selected. This is crucial for the long-term functionality of the sensor. For agressive liquid you can use stainless steel or PE.
The temperature of the liquid also plays an important role here. You can use stainless steel for higher temperature.
Choose your prefered cable or wires type and your optimal length.
The right connector provides a fast and secure connection with the control or submersible pump. You should never switch a 230V pump directly as this destroys the float switch.
Choose your appropriate components. We are happy to support you in the optimal selection.

  • Baugroesse

    Size

    Length from 3cm to 100cm, mounting on request

  • Werkstoffe Schwimmerschalter

    Material

    PA, PP, PE, POM, PVDF, stainless steel, brass, others on request

  • Schwimmer

    Floats

    With integrated Magnet, PP, PA, PE, NBR, stainless steel

  • Reedschalter

    Reed switch

    Switch up to 500V, up to 100W, closer (SPST-NO), opener (SPST-NC) or changeover (SPDT)

  • Litzen / Kabel

    Strands / cables

    For your requirements, in different colors and materials

  • Steckerauswahl

    Plug / stripped

    Suitable for your application, manufacturer according to your specifications

Float switches monitors the filling of a water tank. Mostely you will check if the tank is full or empty. However, other levels can also be monitored. This allows you to monitor the filling in more detail. Depending on the design, the float sensor has 1 or more switching points for the respective level to be detected. For this purpose, several floats are needed.

RS_RSC2004

1 switching point

RS_RSC2004

2 switching points

VK 1173

3 switching points

Level switch structureOur float switches operate according to the simple and durable principle of reed switch technology. The float lifts or lowers along a steep pipe depending on the level of fluid. The magnet in the float switches the reed contact inside the climbing tube without contact. Depending on the positioning of the magnet and reed switch, different switching points can be realized in order to recognize exactly your desired level. Float switches can have one or more switching points.

Compared to other techniques such as inductive, capacitive or ultrasonic, these require no permanent power supply and are very energy-saving. They can be used in almost any environment. Float switches are maintenance-free, durable and easy to assemble. This guarantees low installation and operating costs.

You can attach the level switch to different positions of your container or tank. We generally distinguish between vertical mounting and horizontal mounting.

  • null

    Vertical Mounting

    Installation from top or bottom into the container

By means of a thread at the float switch, it is screwed to the container.

  • null

    Horizontal Mounting

    Installation from the side into the container

Types for plates from outside or inside.

Need more information?

Product examples

Here you can see an exemplary selection of level switches (other designations are also: float switch). We also offer many other product variants. Just ask us.

Using the categories button bar, you can filter the view by assembly type or material. By clicking on the product image or type designation, you will receive further product details and technical data.

Product – categories:
